Our high quality Cat 6a low smoke fully booted snagless patch cables are available in Grey, Yellow, Red, Blue, Green and Black and from 0.5mtr up to 10mtr lengths. Supporting 10GB ethernet compared to the 1GB of Cat6 patch cables these cat6a patch cables will help future proof your network for a long time to come.Ab £1.30Grundpreis /Nicht verfügbar+3Alle EinzelheitenAb £1.30Grundpreis /Nicht verfügbarVAT Included: £1.56Cat5e Crossover UTP Patch cables are perfect if you need to link 2 PCs direct. Cat 5e crossover cable is available in 5 colours from 0.5 mtr up to 20 mtr.Ab £0.80Grundpreis /Nicht verfügbarAlle EinzelheitenAb £0.80Grundpreis /Nicht verfügbarVAT Included: £0.96
Cat5e Extension Cables Male to Female
Cat 5e extension cable is used for extending any existing Cat 5 Ethernet cables by up to 10mtrs.Ab £2.96Grundpreis /Nicht verfügbarAlle EinzelheitenAb £2.96Grundpreis /Nicht verfügbarVAT Included: £3.55Best Selling! Cat 5e cables, flush moulded boot, are perfect for both office and home solutions. Cat5e UTP (Unshielded Twisted Pair) full copper patch cables are available in 10 colours, from 0.25 mtr up to 50 mtr.Ab £0.46Grundpreis /Nicht verfügbar+3Alle EinzelheitenAb £0.46Grundpreis /Nicht verfügbarVAT Included: £0.55Cat5e CCA are manufactured with a copper core and outer aluminum cable to provide the most cost effective solution.Cat5e CCA cable is available in 10 colours from 0.25mtr up to 50 mtrs.Ab £0.48Grundpreis /Nicht verfügbar+3Alle EinzelheitenAb £0.48Grundpreis /Nicht verfügbarVAT Included: £0.58Cat 5e Flat Patch Cables are used for running under carpets to hide cables. Cat5e UTP flat cable is available in 3 colours from 0.5mtr up to 30mtr.Ab £1.20Grundpreis /Nicht verfügbarAlle EinzelheitenAb £1.20Grundpreis /Nicht verfügbarVAT Included: £1.44Cat5e low smoke zero halogen (LSZH or LS0H) cables add security in case of fire as the fumes generated from low smoke cables are less harmful than non low smoke outer sheaths.Cat 5e low smoke cable is available from 0.5 mtr to 10 mtr.Ab £0.87Grundpreis /Nicht verfügbarAlle EinzelheitenAb £0.87Grundpreis /Nicht verfügbarVAT Included: £1.04Cat5e Patch Cables Low Smoke Snagless
Cat5e Patch Cables Low Smoke Snagless patch cables are available in 6 colours from 0.5mtr up to 10mtr lengths. These Cat 5e cables come with a bubble boot that covers the latch on the RJ45 connector.Ab £0.84Grundpreis /Nicht verfügbarAlle EinzelheitenAb £0.84Grundpreis /Nicht verfügbarVAT Included: £1.01CATEGORIES OF ETHERNET CABLES
On the basis of supported speed and frequency, the Ethernet cables are categorized into different categories. The mainly used categories are discussed in following table. The speed is measured in Megabits per second (Mbps) or Gigabits per seconds (Gbps) and frequency is measured in megahertz (Mhz).
Ethernet cable category
Specifications
Description
CAT5
Speed: 10 Mbps to 100 mbps
Frequency: 100 Mhz
CAT5 is the oldest and slowest UTP cable. Now these cables are not available in the stores, but are available with older router or any older networking device.
CAT5e
Speed: 10 Mbps to 1000 mbps
Frequency: 100 Mhz
CAT5e is enhanced CAT5 cable with additional increase in speed and reduced interference level. They support upto 1000 mbps or 1 Gbps of speed so they are often called ‘gigabit Ethernet’.
CAT6
Speed: 10 Mbps to 10 Gbps
Frequency: 250 Mhz
CAT6 is successor of CAT5e with few more improvements in speed and frequency. The crosstalk (i.e. internal interference) is also reduced by making more twists in each copper pair. The new network infrastructures are using CAT6, so they are easily available in market. They require Gigabit compatible hardware for their installation.
CAT6a
Speed: 10 Mbps to 10 Gbps
Frequency: 500 Mhz
With reduced interference capabilities CAT6a allows connections up to longer range at speed of 10 Gbps. It has a plastic separator spine running in centre that decreases the interference.
The cables are often available in many colours like red, green, blue and yellow. These colours are used only for identification and does not symbolise any different type of cable.
Read our blog to know more about Ethernet cables.
Go back at Top PageUNSHIELDED VS SHIELDED
There are different types of Ethernet cable available in market. All Ethernet cables are twisted copper wires because twisting of wires eliminates the interference in internal wires. The cables are broadly classified in two classes; Unshielded Twisted Pair (UTP) and Shielded Twisted Pair (STP).
- The UTP cables are not shielded: this involves a high degree of flexibility and resistance to forces. They are widely used in Ethernet networks and it's the most common solution if electromagnetic interference is not an issue.
- The FTP (Foiled twisted pair) is enhancement of UTP that includes a metallic shield enclosing the entire cable to reduce electromagnetic interference. Shielded cables are used in higher interference area, like running cables outdoors or cables installed inside walls of building. Also, these cables are best to be installed for longer distance connections.
Read our blog to know more about the difference between Unshielded UTP cables and Shielded FTP Cables.
Go back at Top PageBOOT TYPE: MOULDED VS SNAGLESS
- Snag less ethernet cables have a plastic boot that covers the Rj45 plug so it doesn't catch or break off when you are pulling it through a tangle of other cables.
- Moulded cables do not have a latch protection and it makes the cable easier to be removed.
Read our post on the difference between Moulded Cables and Snagless Cables.
Go back at Top PageCABLE TYPE: PVC VS LOW SMOKE
Network cables are insulated with PVC jacket or Low Smoke jacket.
- Ethernet cable with PVC sheath is your “go cable” for installation with no special requirement and it is the most common type of cable used in home network installation.
- Low Smoke Zero Halogen Cable (also known as LSZH and LS0H or Halogen-free cable)does not generate dangerous combination of gas / acids or toxic smoke when exposed to fiamme. These type of cables is increasingly demanded by the authorities for the protection of people and equipment from toxic gases and corrosive and, in any case, slightly ventilate.
Read our blog article on Low smoke Zero Halogen cables if you wish to know more.
Go back at Top PageWIRING SPECIFICATION: STRAIGHT VS CROSSOVER - Straight cable (or direct) is used to connect a PC to your router or network HUB or SWITCH. or to another network device.
- Crossover cable is used to connect with each other apparatuses of the same type as two PC or to cascade connect HUB / SWITCH.
Read our blog article if you want more info on how an ethernet cable is made .
